ZyXEL NWA220AX-6E    WiFi 6E – the Fastest Speed EVER WiFi 6E, the extended version of the WiFi 6, provides a huge innovation leap to wireless industry by taking it into a much wider 6GHz radio spectrum that more than doubles WiFi capacity to further meet today’s demands and tomorrow’s challenges. It includes all the benefits of WiFi 6 capabilities like OFDMA, MU-MIMO, BSS Coloring, and brings them into the brand-new, interference-free 6GHz that more than doubles the WiFi capacity to deliver ultra-fast speed and low-latency connections.    NWA220AX-6E for High-density WiFi WiFi 6E, the new 6 GHz band, presents a solution to quenching the thirst for today’s hunger for more bandwidth. The NWA220AX-6E’s BandFlex radio design allows the AP to support either 5GHz or 6GHz band by configuration, making it the most economical choice to fit into your existing 5GHz coverage, as well as futureproofing the use of 6Ghz. The NWA220AX-6E is a perfect choice for:   Flexible BandFlex radio design The Zyxel NWA220AX-6E is the dual-radio access point with a BandFlex radio design that can support either 5GHz or 6GHz by configuration, making it the most economical choice to fit into your existing 5GHz coverage as well as futureproofing the use of 6GHz.    Wireless StandardIEEE 802.11 ax/ac/n/g/b/aMIMOMU-MIMO Wireless speed2.4GHz: 575 Mbps5GHz: 4800 Mbps6GHz: 4800 Mbps Frequency band2.4 GHz:USA (FCC): 2.412 to 2.462 GHzEurope (ETSI): 2.412 to 2.472 GHz
 5 GHz:USA (FCC): 5.15 to 5.35 GHz; 5.470 to 5.850 GHzEuropean (ETSI): 5.15 to 5.35 GHz; 5.470 to 5.725 GHz
 6 GHzUSA (FCC): 5.925 to 6.425 GHz; 6.525 to 7.125 GHzEuropean (ETSI): 5.925 to 6.425 GHz Bandwidth20-, 40-, 80- and 160-MHzConducted typical transmit output power*1
(limited by local regulatory requirements)US (2.4GHz/5GHz/6GHz): 24/25/24dBmEU (2.4GHz/5GHz/6GHz): 18/22/19dBm  RF Design Antenna type4x4 + 2x2 MIMO Embedded AntennaAntenna gain2.4 GHz: Peak Gain 3dBi5 GHz: Peak Gain 5dBi6 GHz: Peak Gain 6dBiMinimum receive sensitivityMin. Rx sensitivity up to -101 dBm  WLAN Feature Band steeringYesWDS/Mesh*2 < p>YesFast roamingPre-authentication, PMK caching and 802.11r/k/vDCSYesLo ad balancingYesAdvanced Cellular CoexistenceYes  Security EncryptionWEPWPA WPA2-PSKWPA3Authentication WPAWPA2WPA2-Enterpr iseEAPIEEE 802.1XRADIUS authenticationAccess managementL2-isolationMAC filteringRogue AP detection  Networking IPv6YesVLANsYes < /p>WMMYesU-APSDY es
  Management Operating modeNebula cloud managedStandaloneZON UtilityDiscovery of Zyxel switches, APs and gatewaysCentralized and batch configurations:IP configurationIP renewDevice rebootDevice locatingWeb GUI accessFirmware upgradePassword configurationWeb UI/CLIYesSNMPNO   Physical Specifications ItemDimensions (WxDxH)(mm/in. )
180 x 180 x 42 mm / 7.09 x 7.09 x 1.65Weight (g/lb. )
650g/1.43lbPackingDime nsions (WxDxH)(mm/in. )
197 x 190 x 60 mm/ 7.76 x 7.48 x 2.36Weight (g/lb. )
780g/1.72lbIncluded accessoriesMount plateMounting screwsMTBF (hr)711,333  Physical Interfaces Ethernet port1 x 1/2.5Gbps LAN1 x 1Gbps LANPowerPoE (802.3)at: power draw 21 WDC input : 12 VDC 2APoE modesIEEE802.3af: No WirelessIEEE802.3at: UnrestrictedIEEE802.3bt: Unrestricted
