Cudy AP3000         Connects 512 Devices with 512 MB RAM  1.3 GHz dual-core CPU, large RAM, and the upgraded UL/DL MU-MIMO and OFDMA technologies significantly reduce transmission latency to and from the AP when connecting multiple devices. 5 Antennas and 3+2 Strucutre Boost Coverage  Five antennas plus 3+2 structure create more paths to bypass obstacles. Beamforming tracks connected devices' directions and boosts signal towards them.     Specifications Hardware Features Highlights CPU: 1.3 GHz Dual-Core ARM CPUFlash: 256 MB NAND (2 Gbit)DDR: 512 MB DDR4 (4 Gbit)Interface 1× 2.5 Gbps Ethernet Port (PoE In)1× Reset Button1× DC JackPower Supply 802.3af/at PoE48-57 V Passive PoE (+4,5pins; -7,8pins)12 V ⎓ 1.5 A DCPower Consumption PoE Idle: 5.7 W12 V DC Idle: 6.1 WPoE Max: 12 W12 V DC Max: 11 W48 V DC Max: 12 WDimensions (Dia. ×H ) Φ231.9×57.1 mmAntenna Type 4× Internal Omni-directional AntennasMounting Ceiling/Wall MountingWireless Function Wireless Standards Wi-Fi 6 (802.11ax/ac/n/g/b/a)Frequency 2.4 GHz and 5 GHzSignal Rate 5 GHz: Up to 2402 Mbps2.4 GHz: Up to 571 MbpsChannel Width 20/40/80/160 MHzWireless Functions(Features with * require a Cudy AC as the gateway, Cudy AC's ETA is 2024 Q2)(Features with ** require a Cudy WR1300 or Cudy AC as the gateway)(Features with △ require a Cudy Mesh router/Mesh unit or Cudy AC as the gateway)  Captive Portal **Seamless Roaming Mesh△Self-Organizing Mesh△Band Steering*Auto Channel Optimization*Enable/Disable Wireless RadioTransmit Power Control QoS (WMM)MU-MIMOBeamformingRate LimitReboot ScheduleWireless ScheduleWireless Encryption WPA-PSK, WPA2-PSK, WPA3-SAE, WPA-PSK/WPA2-PSK, WPA2-PSK/WPA3-SAE Security(Fe atures with * require a Cudy AC as the gateway) IP/MAC FilteringAP Isolation*Operating Modes Wireless Access Point ModeWireless Router ModeWireless Extender ModeWISP ModeEnvironments Operating Temperature: 0~40 °CStorage Temperature: -40~70 °COperating Humidity: 10~90% RH non-condensingStorage Humidity: 5~90% RH non-condensingSystem Requirements Windows, MAC OS, NetWare, UNIX, or LinuxFirefox 12.0+, Chrome 20.0+, Safari 4.0+, or other web browserA fiber/cable/DSL Modem, or other devices providing wired internet Subscription with an internet service provider for internet accessA power socket for AC power supply, or PoE power supplyAdvanced business AP features require a Cudy AC as the gateway, Cudy AC is coming soon in late 2023. Mesh features require a Cudy Mesh unit/Mesh router or AC as the gateway with firmware newer than 15.28.

Продукт известен още и като AP 3000
